R-410A HFC refrigerant
-
Complete factory charged, wired and run tested
-
Scroll compressors with internal line break overload and highpressure protection.
• Single stage compressor on all models
-
Convertible airflow
-
TXV refrigerant metering system on each circuit
-
High Pressure and Low Pressure/Loss of charge protection standard on all models
-
Solid Core liquid line filter drier on each circuit
-
Single slab, single pass designed evaporator coil facilitate easy cleaning for maintained high efficiencies
-
Cooling operation up to 125 degree F ambient
-
Easily removable filter, blower, gas heat, and compressor/control access panels permits prompt service
-
Powder Paint Finish meets ASTMB117 steel coated on each side for maximum protection. G90 galvanized
-
One piece top cover and one piece base pan with drawn supply and return opening for superior water management
-
Externally mounted refrigerant gauge ports for easy service diagnostics
-
Easy to install plug-in; slip in, 100% fully modulating economizer
-
Forkable base rails for easy handling and lifting
-
Single point electrical and gas connections
-
High performance belt drive motor with variable pitch pulleys and quick adjust belt system
-
Permanently lubricated evaporator, condenser and gas heat
inducer motors
-
Condenser motors are internally protected, totally enclosed with shaft down design
-
1 inch filter standard with slide out design
-
Single stage gas valve, direct spark ignition, and induced draft for efficiency and reliability
-
Tubular heat exchange for long life and induced draft for efficiency and reliability
-
Solid state furnace control with on board diagnostics
-
Colored and labeled wiring
-
Copper tube/Aluminum Fin coils
-
Factory Installed ClearControl™, Direct Digital Control (DDC) and sensors which can connect to LonWorks™ or BACnet® BAS systems for remote monitoring and control
